DIHR GS50 Single-Phase Undercounter Dishwasher â 500mm Basket

The DIHR GS50 single-phase undercounter dishwasher is designed for medium-sized restaurants, busy bars, hotels and commercial catering operations. Its 500 — 500mm basket provides practical capacity for washing plates, glassware and utensils, while two wash cycles allow operators to select either 120 or 180 seconds. The machine processes up to 30 racks per hour and uses approximately 2.3 litres of water per cycle. Durable AISI 304 stainless steel construction, a double-skin door and Thermostop-controlled rinsing support reliable daily performance. Its 220V single-phase configuration makes it suitable for commercial kitchens without three-phase electrical access.

Features

• AISI 304 stainless steel construction

• Sound and heat-insulated double-skin door

• Anti-shock door security system

• Deep-drawn sloped tank improves drainage

• Non-drip roof protects washed items

• Composite wash and rinse arms

• Removable nozzles simplify daily cleaning

• Integrated wash pump protection system

• Non-return valve prevents water backflow

• Thermostop-controlled 85C rinse cycle

• Built-in rinse-aid dispenser

• Two selectable wash cycles

Specifications

• Wash cycles: 120 and 180 seconds

• Maximum output: 30 racks hourly

• Water use: 2.3 litres per cycle

• Basket size: 500 — 500mm

• Maximum loading height: 325mm

• Wash temperature: 55C

• Rinse temperature: 85C

• Tank capacity: 29 litres

• Boiler capacity: 5.7 litres

• Supply voltage: 220V single phase

• Installed power: 3.45kW

• Dimensions: 590 — 600 — 850mm

• Weight: 65kg

What’s in the Box

• 1 — DIHR GS50 Dishwasher

• 1 — Plate rack

• 1 — Glass rack

• 1 — Cutlery holder

• User documentation, where applicable
